SSISDB Error “The version number of the package is not valid”

23 Sep

The full message will also contain “The version number cannot be greater than the current version number”.

Behaviour

I have an SSIS package installed in an SSISDB which is on a server that run SQL Server 2012 (server A) and it needed to be copied to another 2012 instance (server B). My workstation has SQL Server 2014 and I connect to the 2012 instance on the target server using my workstation instance.

I connected from my workstation to Server A and exported the SSIS package into the required ‘ispac’ file. Then changed my connection to point to Server B and imported the ispac file. So for both the export and import I was using my SQL Server 2014 to connect to SQL Server 2012 instances.

The export and import run without any issues, but when the associated job executed that ran the SSIS package on Server B, it failed. In this case the important part of the error report was:
“Package migration from version 8 to version 6 failed with error 0xC001700a. the version number in the package is not valid. The version number cannot be greater than the current version number.”

Cause

Exporting the SSIS package by using SQL Server 2014 (even though it is connecting to a 2012 instance) appears to have changed the ‘PackageFormatVersion’ property within the dtsx file, form ‘6’ to ‘8’. You can see this by opening the dtsx file in an editor such as Notepad++. Editing that value back to ‘6’ merely corrupts the package, so there are probably further changes made within the file.

Solution

Connect to the required instance using SQL Server Management Studio (SSMS) that matches that version in order to complete this export/import. In my case I could remote onto the required servers and use the SSMS for SQL Server 2012 that was installed there. The export and import worked as expected and this time the SSIS package ran without issue.

SSIS Error – “To run a SSIS package outside of SQL Server Data Tools you must install…”

25 Jul

Background

On a Dev server I have used Visual Studio 2010 to build and test an SSIS package. Having completed all of my testing I have now created an Agent task with the SQL Server instance on the same box, that should execute the dtsx package.

However, when it attempts to execute it fails and I see the error message:

“To run a SSIS package outside of SQL Server Data Tools you must install Move file to Archive of Integration Services or higher.”

In this case ‘Move file to Archive’ is the name of a task within the SSIS package, which is of course, moving a file to an archive folder.

Not the most helpful error message.

Investigations

Running the installation of SQL server (or executing a Service Pack installation), up to the point where it shows what is already installed shows that the Integrated Services shared components are not installed:

SSIS_01

On this machine, although SQL server is installed, the shared components required for Integration Services are not. In this situation it is still possible to run very simple SSIS packages, because ‘dtsexec.exe’ is installed. This explains why I can see an Agent job that runs a package for running backups (created by the Maintenance Plan Wizard) but cannot execute my package.

Solution

Rerunning the installation confirms the absence of Integration Services components:

SSIS_02

I installed the required components and then confirmed their presence afterwards:

SSIS_03

Now the SSIS package executes successfully.
